Details
Pedal beyond the unknown
Get ready to go beyond your usual ride—the Hatchet Vista will take you to new places. With its redesigned aesthetic and full accessory compatibility, this gravel explorer is the ultimate adventure companion. Whether you’re tackling an all-day epic, discovering hidden trails, or planning an overnight escape under the stars, the Hatchet Vista is built to handle it all. Its updated geometry prioritizes comfort for long days in the saddle, and the full carbon fork complements this with optimal vibration absorption and agile handling, making it perfect for everything from short off-road adventures to bikepacking weekend trips. Backed by a lifetime warranty, because the adventure never stops. Pedal beyond the unknown with the new Hatchet Vista.
Technologies:
Optimum R03 6061-T6 Aluminum frame
The technology of Optimum R03 aluminum frames - Hydro-formed, the 6061-T6 aluminum tubes are triple reinforced. They are thinner where weight can be saved and thicker in areas of significant tension, creating a frame that is both light and durable with excellent power transfer and amazing comfort.
Lifetime warranty
The love of riding lasts a lifetime. Now your bike can too.
Updated Geometry
The Hatchet Vista's updated geometry prioritizes comfort for long days of exploration on the saddle.
Full Carbon OSC Fork
The full carbon fork of the Hatchet Vista is designed with the same intentions that define our OSC carbon blend: optimal stiffness and exceptional durability. In terms of performance, expect ultra-responsive handling while also making the bike lighter.
Accessory ready. Adventure ready.
Versatile compatibility with a wide range of accessories to equip your bike for any adventure.
Accessory mounts
The Hatchet Vista offers unmatched flexibility with six distinct mounting options: four integrated into the frame and two on the fork.
Internal cable routing
Sleek internal routing from the headtube to the chainstay keeps debris out to deliver long-lasting performance and creates a super-clean profile.
700c x 45 mm tire clearance
700c x 45 mm for capable mud ejection plus the traction you want when venturing off the pavement.
Universal Derailleur Hanger
Reduces the risk of damaging your derailleur and simplifies sourcing replacement parts when needed.
Threaded T47 Bottom Bracket
The T47 bottom bracket standard offers enhanced durability, ease of installation, and improved performance with wider bearings.
Fork with capped axle
Streamlined fork with debris-shunning capped axle for fast, clean aesthetics.
Room for 3 bottles
All frame sizes are designed to accommodate up to three bottles: two inside the front triangle and a third one positioned beneath the down tube.
Compatible with SRAM Full Mount derailleur
Since the Hatchet Pro is equipped with a UDH hanger, it is also compatible with SRAM Full Mount derailleurs.
Compatible with front and rear fenders
Frame and fork feature internal discrete fender mounts for clean aesthetics.
Rear rack-ready
Want to add a rear rack? No problem.
Side-Cage Compatible Fork
The fork features three mounting bosses for side cages or other practical bikepacking accessories.
Dropper seatpost compatible
The Hatchet Vista frame can accommodate a dropper seatpost, providing an easy upgrade for anyone looking to gain that extra drop when needed.
| XS - 50cm | S - 52cm | M - 54cm | L - 57cm | XL - 60cm | |
|---|---|---|---|---|---|
| A - ST (MM) | 400 | 440 | 490 | 530 | 570 |
| B - SA (DEG) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| C - HA (DEG) | 70.5 | 70.5 | 70.5 | 70.5 | 70.5 |
| D - TT (MM) | 532 | 548 | 562 | 577 | 598 |
| E - REACH (MM) | 376 | 383 | 390 | 397 | 404 |
| F - CS (MM) | 428 | 428 | 428 | 428 | 428 |
| G - WB (MM) | 1014 | 1031 | 1047 | 1063 | 1078 |
| H - BBH (MM) | 283 | 283 | 283 | 283 | 283 |
| BBD (MM) | 70 | 70 | 70 | 70 | 70 |
| I - SOH (MM) | 675 | 710 | 751 | 786 | 821 |
| J - STACK (MM) | 530 | 559 | 582 | 610 | 634 |
| K - HT (MM) | 110 | 140 | 165 | 195 | 220 |
| RIDER HEIGHT (CM) | 147-160 | 157-171 | 169-180 | 178-187 | 185-193 |
Specs
| Frame | Aluminum Optimum R03 |
|---|---|
| Fork | Carbon OSC |
| Rims | V2 Comp db | 25mm inner | TR |
| Hubs | Shimano TC500-12 Disc | Centerlock | TA 12x100mm/Shimano TC500-MS Disc | Centerlock | TA 12x142mm |
| Spokes | Stainless 14G |
| Tires | WTB Resolute | 700x42c | TR |
| Bottom Bracket | FSA BB-6002 | T47 |
| Crankset | Shimano GRX610 | 40T |
| Shifters | Shimano GRX610 | 12s |
| Rear Derailleur | Shimano GRX822 | 12s |
| Cassette/Freewheel | Shimano Deore M6100 | 11-51T | 12s |
| Chain | Shimano M6100 | 12s |
| Brakes | Shimano GRX610 | Hydraulic | Flat Mount |
| Rotors | Shimano RT-54 | 160mm | Centerlock |
| Handlebars | V2 Pro | B:31.8mm | R:70mm | D:125mm | 16° FLARE |
| Tape/Grips | Super Soft |
| Stem | V2 Pro | B:31.8mm | 6° |
| Headset | FSA no.55R | Internal Routing |
| Seatpost | Devinci | 27.2mm |
| Saddle | Devinci |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Bronzite / X-Small / 700c | 883385244180 | FV25079132 | |
| Bronzite / Small / 700c | 883385244210 | FV25079232 | |
| Bronzite / Medium / 700c | 883385242087 | FV25079332 | 210000021062 |
| Bronzite / Large / 700c | 883385241349 | FV25079432 | 210000021063 |
| Bronzite / X-Large / 700c | 883385246054 | FV25079532 |
